M-Code version of SHOUT ts




The SHOUT tsM is a standard SHOUT tracking device but with M-Code capabilities. When the user detects that the GNSS signal is jammed/spoofed the user can switch to M-Code for a hardened GPS signal. The SA tab on the front screen of the SHOUT tsM device will display the current interference level detected by either receiver, and that’s how the user will know if the signal is degraded. The SHOUT tsM still uses Iridium Short Burst Data (SBD) service for 2 way messaging communications, can send near real-time tracking reports, and contains an emergency alert switch.

To request a quote, please contact sales@nalresearch.com.

Key Features

• Body-worn Tracker and Messaging Device
• Real-time, Pole-to-Pole Coverage
• Commercial GNSS & M-Code A-PNT Capability
• Compatible with Iridium
DoD or Commercial Gateways
• 256-bit AES Encryption for Secure Messaging
• IP67 Rated
• Automated Location Reports
• Guarded 911 Alert Switch
• High Resolution Touchscreen
• Free-text & Pre-Defined Messages
• USB Interface and Internal
Rechargeable Battery
• Compatible Airtime Service(s): SBD


Dimensions 4.76” L x 2.90” W x 1.20” D (122mm x 74 mm x 31 mm)
Weight 16 oz (453 grams)
Battery 6.6A-Hr rechargeable Lithium Ion
I/O Interface: USB C
Input Voltage Range: 2.7VDC to 5.5VDC
Operating Temperature: -4°F to +140°F (-20°C to +60°C)
Operating Humidity: < 75% RH



Product Sheet

SHOUT tsM Quick Start Guide (rev A 2023-03-21)
