SHOUT pt

Description

The SHOUT pt is a global, multi-source Assured Position, Navigation and Timing (A-PNT) handheld device capable of providing layered, assured position and time in the presence of adversary and environmental threats to GPS signals. The SHOUT pt’s hierarchal engine automatically selects the optimal PNT source based on accuracy, integrity, and power management. It is powered by a commercial 5G mobile platform and is designed to support future software defined radio (SDR) capabilities. The SHOUT pt’s high resolution color touchscreen is day/night compatible and natively hosts the integrated ATAK app, including waypoint navigation. The SHOUT pt supports user wearable devices via secure Bluetooth and displays info on the Nett Warrior End User Device (EUD) through the USB connection. Replaceable, external 6.6 A-Hr rechargeable Li-Ion battery.

Additional Features:

• AES-256 Encryption for Secure
• Messaging with Wearable
• Commercial 5G Mobile Platform
• SDR Enabled Future Waveform Integration
• High Resolution Touchscreen
• USB Interface
• Rechargeable, Replaceble Battery
• IP67 Rated, 1 meter @ 30 min
• OCXO Stabilized 1PPS Timing

Use Cases

Capable of providing assured Position, Navigation and Timing in the presence of adversary and environmental threats to GPS signals. The SHOUT pt engine utilizes up to five separate PNT sources to provide assured navigation:

• M-code GPS receiver
• High-accuracy commercial
• GNSS receiver
• Alt-RF receiver
• Visual Inertial Odometry
• IMU Advanced Sensor Fusion
